QUICK 3 STEP VOLTAGE CONVERTER SELECTION GUIDE

Use your U.S. Electric Products
on Foreign Voltage with
our quick 3 step voltage converter
selection guide

LEARN MORE

3-Quick Step Voltage Converter Guide

Step 1) Determine the Voltage Rating
Look for the AC voltage rating of your electric item. Voltage rating is often stated on the specification side of the item or on its power supply adapter and it is indicated with a "V" or "VAC".

Your item's voltage rating should fall within these three groups:
Dual Voltage Rating 100-240V
A
100-240V
also know as
Dual Voltage
Sample 120V rating
B
120V
or
110-125V
sample 230v rating
C
230V
or
220-240V

A) If your item is rated 100-240V then it is dual voltage and its designed to operate on any voltage without a voltage converter or a voltage transformer. You'll just need a correct adapter plug for the country you want to use it in. Plug adapters are listed here.

B) Items rated at 110-125V require a step down voltage converter or voltage transformer for use in 220-240V countries. Proceed to step 2 to determine which voltage converter.

C) Items rated at 220-240V require a step up voltage converter or voltage transformer for use in 110-120V countries. Proceed to step 2 to determine which voltage converter.

Step 2) Determine the power requirement of your item (WATT)
Now that you know that your item requires a voltage converter or transformer, you'll need to find the WATT (W) or the AMP (A) rating to determine the correct size voltage converter. As shown in the step 1 above, look for this information on the specification sheet of your item.


Some examples:
Sample 120V rating
A
23W
sample watt rating
B
220V - 500mA
watt rating sample
C
240V - 1.8A

A) *Fairly simple, as 'W' is clearly stated in this case 23W. Proceed to step 3.
B) Calculate W = V x A, and 1000 mA is 1A so in this case 220V x 0.50A = 110W. Proceed to step 3.
C) Calculate W = V x A, so in this case 240V x 1.8A = 432W. Proceed to step 3.
*Note you may find a range of wattage rating, i.e 1200W - 2000W on an item so in that case select the MAX wattage rating.

Step 3) Purchase the correct size voltage transformer
Now that you know your items' Voltage and Watt ratings we can determine the correct voltage converter or transformer for your item. All of our heavy duty transformers are designed for continuous use and function as step up and step down transformers. Electronics items often surge or spike when they are switched on causing the wattage ratings to exceed the specification sheets. Thus, it is always best to purchase a transformer larger than your items required wattage to handle any power surges that may occur. The best way to figure out which transformer to purchase is by multiplying the wattage rating of your item times the efficiency factor of the transformer you select.

Efficiency factors of all the transformers that we sell:
E-Factor 1.25 1.5 2.0 2.5
Transformer
Model
LiteFuze convertingbox LiteFuze VT series LiteFuze LR series
Seven Star TC series
Seven Star  ST
Seven Star AR
Seven Star THG

E.Factor x Watt of your item = Min. Watt required of the corresponding E. factor transformer

If your item is 150W:

1.25 x 150 = 187.5W -> LiteFuze convertingbox 200
1.50 x 150 = 225W -> LiteFuze VT-300
2.00 x 150 = 300W -> LiteFuze LR-500 or Seven Star TC-300
2.50 x 150 = 375W -> Seven Star ST-500 or Seven Star AR-500
*Lower efficiency factor equals the better quality of the voltage transformer.


Why is the LiteFuze convertingbox the most recommended and top selling transformer?


Can I use U.S 125V Power strips or Surge Protectors with voltage transformer to connect multiple items?
No, the way U.S. power strips or surge protectors are configured they will burn out when used it a transformer even when output is at 110V. We recommend the 250V power strips to use with voltage converters. The 250V universal power strips will work on any voltage and accept any type of plugs.

Need help or have more questions?
Call us at 847-983-4761 or read our voltage converter guide or  tips and hints when using voltage converters. You may also discuss voltage converter, transformers and adapter on the forums.
