OREI 1x4 HDMI Extender Splitter - 395 Feet
The OREI HD-EX104 is the perfect solution for splitting and extending your HDMI signal with Full HD resolution to multiple displays over long distances. It uses PermiumHD technology to split 1 HDMI source to 4 displays simultaneously over a single CAT5/5e/6 cable for each display up to 120m / 400ft, any one of four PermiumHD receiver works with the splitter individually, and the highest resolution supported is 1080p@60Hz.
This product supports the Over IP function so that you can add multiple receivers by connecting it with a network switch as a mediator. It supports one to many connections (sold separately).
Package Contents & Warranty:
-
Includes:
- 1x Transmitter
- 4x Receivers
- 1x IR Blaster Cable
- 4x IR Receiver Cables
- 5x Power Adapters
- 1x User Manual
-
Warranty:
- 1 Year OREI Manufacturer's Warranty
Key Features:
- Supports 20 ~ 60Hz IR Pass Back
- Output 1080p signal up to long-distance of 120 m / 400 feet with Cat5e/6/7 cable
- This product supports the Over IP function so that you can add multiple receivers by connecting it with a network switch as a mediator. It supports one to many connections (sold separately)
- It extends HDMI audio/video signals to synchronous
- Supports cascade connection using a LAN switch or router
- The output video display is as fluent as the direct connection
- Surround sound up to 7.1-channel or stereo digital audio
- Compatible with ProLNK receiver device
- Compatible with HDCP compliant devices & content
- Control a DVD Player or Other HDMI Video Source from a Remote Location with the included IR cables that forward commands over a dedicated DDC Channel
- Lossless Transmission with Minimal Latency
- Ideal Solution for HDMI Exhibition, Video Conference, Meeting rooms and Bars, etc.
- Plug & Play Setup without any Software Installation
OREI 4 Ports HDMI Extender Splitter
- Input Ports: 1x HDMI
- Output Ports: 4x RJ45
- HDMI Signal: Compatible with HDCP
- Transport Protocol: ProLNK
- Video Resolutions: 1080p@50/60Hz, 1080i@50/60Hz, 720p@50/60Hz, 576p@50Hz, 576i@50Hz, 480p@60Hz, 480i@60Hz
- Transmit Distance: Upto 120 meters transmission distance for 1080p @ 60Hz over single CAT6
- IR Signal: Support 20 ~ 60kHz IR device
- Connection Indicators Leds: 4x LED
- Working Temperature: 0°C ~ 60°C
- Dimension: 252 mm x 97.5 mm x 25mm
- Weight: 535g
- Color: Black
- Power Consumption: <10W
- Power Supply: 5V2A
- Includes:
- 1x Transmitter
- 4x Receivers
- 1x IR Blaster Cable
- 4x IR Receiver Cables
- 5x Power Adapters
- 1x User Manual
- Warranty:
- 1 Year Manufacturer's Warranty
Request a Quote
OREI HD-EX104: 1x4 HDMI Extender Splitter Over CAT5/6 Up to 395 Feet at 1080p@60hz
