OREI 4K HDMI EXTENDER BALUN UP TO 40 KM
The UHD-FO10-K can extend an HDMI signal up to 33000 feet/10km over single-mode fiber cable. It supports video resolution up to 4K@60Hz 4:4:4 with 18Gbps video bandwidth. The transmitter features an HDMI loop output to connect a display near the source. EDID Management through the switches on the Transmitter. Audio Extraction through 3.5mm output on the Receiver end. It features Bi-directional IR which enables control to and from the Transmitter and Receiver. RS-232 pass-through. Metal enclosure for durability and heat dissipation.
Package Includes UHD-FO10-K(Transmitter and Receiver), 1x IR Kit(Blaster and Receiver), 2x Power Adapter,2 × 3-pin 3.81mm Phoenix Connector, and User Manual.
Key Features:
- HDMI 2.0b, HDCP 2.2, and DVI 1.0 compliant.
- 18Gbps video bandwidth.
- Video resolution up to 4K@50/60Hz 4:4:4.
- HDMI audio formats: LPCM2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD.
- 3D and HDR video support.
- Transmission distance up to 33000 feet/10km (over single-mode fiber cable).*It is possible to use multi-mode fiber with these SFP modules but the distance can not be guaranteed.
- Bi-directional IR enables control to and from the Transmitter and Receiver.
- RS-232 pass-through and EDID management for simple and convenient control.
- The transmitter features an HDMI loop output to connect a display near the source.
- Audio Extraction through 3.5mm output on the Receiver end.
- Compact design for easy and flexible installation.
CONNECTIVITY
Transmitter: INPUT PORTS:1 × HDMI IN [Type A, 19-pin Female]
:1 × LINE IN [3.5mm Stereo Mini-jack]
:1 × IR IN [3.5mm Stereo Mini-jack]
:1 × RS-232 [3.81mm Phoenix Connector]
:1 × SERVICE [Micro USB, Update Port]
OUTPUT PORTS: 1 × HDMI OUT [Type A, 19-pin Female]
:1 × Optical Fiber Out [LC Female]
:1 × IR OUT [3.5mm Stereo Mini-jack]
Receiver: INPUT PORTS:1 × Optical Fiber In [LC Female]
:1 × IR IN [3.5mm Stereo Mini-jack]
:1 × SERVICE [Micro USB, Update Port]
OUTPUT PORTS:1 × HDMI OUT [Type A, 19-pin Female]
:1 × RS-232 [3.81mm Phoenix Connector]
:1 × IR OUT [3.5mm Stereo Mini-jack]
:1 × AUDIO OUT [3.5mm Stereo Mini-jack]
AUDIO AND VIDEO
Video Bandwidth: 18Gbps
Video Resolutions: 480i ~1080p50/60Hz, 2560x1440@24/30/50/60Hz, 4K@24/30Hz, 4K@60Hz
Color Space: RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0
Color Depth: 8-bit, 10-bit, 12-bit
HDMI Audio Formats: LPCM 2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD,DTS, DTS-EX,DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
COMPLIANCES
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2
SUPPORTED CAT CABLES
CAT5e, CAT6, CAT7: We recommend you to use shielded CAT6 cables & High-Quality HDMI Cables for optimum performance
EXTENDING DISTANCE
1080p@60Hz: 33000 Feet
FUNCTIONS
EDID Dial the switch to set EDID
LOOP-OUT/LOCAL PORT
Has loop out port: Yes
Number of Loop out ports: 1
SIGNALS
TMDS Signals: -
DDC Signals: -
PROTECTION
Operation Temperature: 32~104°F / 0~40°C
Storage temperature: -4~140°F / -20~60°C
Relative Humidity: 20~90% RH (Non-condensing)
ESD Protection: Human-body Model: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
RJ-45 CONNECTOR TYPE
WE/SS 8P8C
POWER
Power Consumption (Max): Transmitter: 3.85W (Max.)
Receiver: 2.7W (Max.)
Power Supply: Input: AC 100~240V 50/60Hz
Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified)
DIMENSIONS & WEIGHT
Transmitter: Height: 18mm
Width: 134mm
Depth: 68mm
Weight: 280g
Receiver: Height: 18mm
Width: 134mm
Depth: 68mm
Weight: 278g
PROPERTIES
Color: Black
Housing: Metal Enclosure
Transmitter: INPUT PORTS:1 × HDMI IN [Type A, 19-pin Female]
:1 × LINE IN [3.5mm Stereo Mini-jack]
:1 × IR IN [3.5mm Stereo Mini-jack]
:1 × RS-232 [3.81mm Phoenix Connector]
:1 × SERVICE [Micro USB, Update Port]
OUTPUT PORTS: 1 × HDMI OUT [Type A, 19-pin Female]
:1 × Optical Fiber Out [LC Female]
:1 × IR OUT [3.5mm Stereo Mini-jack]
Receiver: INPUT PORTS:1 × Optical Fiber In [LC Female]
:1 × IR IN [3.5mm Stereo Mini-jack]
:1 × SERVICE [Micro USB, Update Port]
OUTPUT PORTS:1 × HDMI OUT [Type A, 19-pin Female]
:1 × RS-232 [3.81mm Phoenix Connector]
:1 × IR OUT [3.5mm Stereo Mini-jack]
:1 × AUDIO OUT [3.5mm Stereo Mini-jack]
AUDIO AND VIDEO
Video Bandwidth: 18Gbps
Video Resolutions: 480i ~1080p50/60Hz, 2560x1440@24/30/50/60Hz, 4K@24/30Hz, 4K@60Hz
Color Space: RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0
Color Depth: 8-bit, 10-bit, 12-bit
HDMI Audio Formats: LPCM 2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD,DTS, DTS-EX,DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
COMPLIANCES
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2
SUPPORTED CAT CABLES
CAT5e, CAT6, CAT7: We recommend you to use shielded CAT6 cables & High-Quality HDMI Cables for optimum performance
EXTENDING DISTANCE
1080p@60Hz: 33000 Feet
FUNCTIONS
EDID Dial the switch to set EDID
LOOP-OUT/LOCAL PORT
Has loop out port: Yes
Number of Loop out ports: 1
SIGNALS
TMDS Signals: -
DDC Signals: -
PROTECTION
Operation Temperature: 32~104°F / 0~40°C
Storage temperature: -4~140°F / -20~60°C
Relative Humidity: 20~90% RH (Non-condensing)
ESD Protection: Human-body Model: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
RJ-45 CONNECTOR TYPE
WE/SS 8P8C
POWER
Power Consumption (Max): Transmitter: 3.85W (Max.)
Receiver: 2.7W (Max.)
Power Supply: Input: AC 100~240V 50/60Hz
Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified)
DIMENSIONS & WEIGHT
Transmitter: Height: 18mm
Width: 134mm
Depth: 68mm
Weight: 280g
Receiver: Height: 18mm
Width: 134mm
Depth: 68mm
Weight: 278g
PROPERTIES
Color: Black
Housing: Metal Enclosure
Includes
- 1 × UHD-FO10-K (Transmitter)
- 1 × UHD-FO10-K (Receiver)
- 1 × IR Blaster cable (1.5m)
- 1 × IR Receiver cable (1.5m)
- 2 × 5V/1A Power Adapter
- 2 × 3-pin 3.81mm Phoenix Connector
- 1 × User Manual
- 1 - Year Manufacturer's Warrant
