ToVi X4 4K Wall Plate Encoder (Video Wall, KVM) - (X4UH-WUC-ETX)

PRODUCT CODE:

ToVi X4 4K Wall Plate Encoder (Video Wall, KVM) - (X4UH-WUC-ETX)

~~$799.00~~ $549.00

In Stock: Usually Ships in 24 Hours

18Gbps Video Bandwidth
KVM & USB 2.0
HDCP 2.2 & DP 1.2 Compliant

Quantity:

REQUEST A QUOTE

FREE SHIPPING WITHIN *USA ON ORDERS $50 & MORE

ToVi X4 Series (4K) w/ KVM

X4UH-WUC-ETX is a high-performance AV over IP Encoder designed for professional AV distribution over a Gigabit network. Built on advanced JPEG2000 technology with ASPEED AST1530 for image compression, it ensures visually lossless 4K@60Hz 4:4:4 video transmission with ultra-low latency, ideal for KVM and interactive applications. This wall-plate encoder features dual HDMI™ and USB-C inputs, supporting automatic and manual switching between sources, along with audio embedding and de-embedding, USB 2.0/KVM functionality, bi-directional RS-232 and CEC pass-through. With support for advanced video formats like HDR10, Dolby Vision, and HLG, and comprehensive audio compatibility including Dolby Atmos, DTS:X, and LPCM up to 7.1CH, the X4UH-WUC-ETX is a reliable solution for demanding AV installations in conference rooms, educational facilities, and control centers. The system is Linux-based for enhanced stability and offers flexible control via Web GUI, RS-232, TCP/IP, and third-party control systems. Its smart networking design, PoE support, and compact 2-gang wall-plate form factor make it easy to install and manage.

Note: The X4UH-WUC-ETX supports RTSP stream preview through VLC with max resolution up to 1080p@60Hz with options for Width, Height, Frame Rate, Bandwidth, Aspect Ratio and Encode Quality Number setting.The sub stream URL examples are mentioned below.
URL: http://IP:PORT/?action=stream&w=x&h=x&fps=x&bw=x&as=x&mq=x

Example 1 (normal stream):
http://ast4-client82C564BB84B5:8080/?action=stream

Example 2 (with output adjustments):
http://169.254.8.65:8080/?action=stream&w=320&h=240&fps=30&bw=8000& as=0

Key Features:

HDCP 2.2 & DP 1.2 Compliant – Ensures compatibility with modern content protection and DisplayPort standards.
Video Resolutions – In addition to pristine 4K@60Hz (4:4:4), it supports high-refresh rate and multi-resolution formats such as 1080p@120Hz, 2560×1440@25/30/60Hz, and 4096×2160@25/30/60Hz.
18Gbps Video Bandwidth – Delivers uncompressed, high-quality video signals.
Long-Distance Transmission – Extends signals up to 328ft (100m) over Cat6/6A/7 cables.
HDMI™ & USB-C Dual Inputs – Supports automatic or manual source switching for flexible operation.
USB-C Data & Charging – The USB-C 1 port enables video, audio, USB data transfer, and device charging via adapter on USB-C 2 port.
Full Signal Transmission Over IP – Transmits video, analog audio, RS232, CEC, and USB signals over Ethernet.
KVM & USB 2.0 Support – Ideal for interactive and control applications, with camera and peripheral support.
Audio Embedding & De-embedding – Flexible audio routing for AV system integration.
Intelligent Video Wall Support – Supports point-to-point, video matrix, and video wall configurations up to 9x9.
MJPEG Sub stream – Allows real-time video preview via portable devices or control apps.
Comprehensive Control Options – Web GUI, RS-232, TCP/IP, Telnet, SSH, and third-party system support
HDR & Dolby Vision Pass-through – Ensures compatibility with high dynamic range content including HDR10, Dolby Vision, and HLG.
Premium Audio Formats – Supports LPCM 2.0/5.1/7.1CH, Dolby Digital, Dolby Atmos, DTS:X, and more.
Power over Ethernet (PoE) – Simplifies installation with standard 802.3at PoE or local 12V power option.
US 2-Gang Wall-plate Design – Compact, professional form factor for discreet in-wall installations.
Smart Networking Design – Optimized for use with 1G Ethernet switches, routers, and hubs for flexible system deployment

CONNECTIVITY
Transmitter: INPUT: 1 x HDMI™ [Type A, 19-pin female]
2 x USB [Type C, 24-pin female]
1 x AUDIO [3pin-3.5mm Phoenix connector]
OUTPUT: 1 x AUDIO [3pin-3.5mm Phoenix connector]
CONTROL: 1 x RS-232 [3pin-3.5mm Phoenix connector]
1 x LAN (PoE) [RJ45]
1 x USB 2.0 HOST [USB Type B, 4-pin female]
2 x USB 2.0 [USB Type-A, 4-pin female]
SUPPORTED CAT CABLES
CAT6, CAT7: We recommend you use shielded CAT6 cables & High-Quality HDMI Cables for optimum performance
EXTENDING DISTANCE
4K@60Hz: 328 Feet
VIDEO OUTPUT
Video Bandwidth: 18Gbps
Video Resolutions: 640x480p60Hz, 800x600p60Hz, 1024x768p60Hz, 1280x1024p60Hz, 1360x768p60Hz, 1440x900p60Hz, 1440x1050p60Hz, 1600x1200p60Hz, 720x480i59.94Hz(480i59), 720x480p59.94Hz(480p59), 720x576i50Hz(576i50), 720x576p50Hz(576p50), 1280x720p50Hz (720p50), 1280x720p59.94Hz(720p59), 1280x720p60Hz(720p60), 1920x1080i50Hz(1080i50), 1920x1080i59.94Hz(1080i59), 1920x1080i60Hz(1080i60), 1920x1080p23.98Hz(1080p23), 1920x1080p24Hz(1080p24), 1920x1080p25Hz(1080p25), 1920x1080p29.97Hz(1080p29), 1920x1080p30Hz(1080p30), 1920x1080p50Hz(1080p50), 1920x1080p59.94Hz(1080p59), 1920x1080p60Hz(1080p60), 3840x2160p23.98Hz(2160p23), 3840x2160p24Hz(2160p24), 3840x2160p25Hz(2160p25), 3840x2160p29.97Hz(2160p29), 3840x2160p30Hz(2160p30), 3840x2160p50Hz(2160p50), 3840x2160p59.94Hz(2160p59), 3840x2160p60Hz(2160p60), 4096x2160p23.98Hz, 4096x2160p24Hz, 4096x2160p25Hz, 4096x2160p29.97Hz, 4096x2160p30Hz, 4096x2160p50Hz, 4096x2160p59.94Hz, 4096x2160p60Hz
Color Space: RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0
Color Depth: Input: 8/10/12-bit, 8-bit (4K60Hz 4:4:4) Output: 8-bit
Video Compression Standard: JPEG2000
Video Network Bandwidth: 1G
ADDITIONAL FEATURES
CEC: Yes
ARC: No
USB KVM: Yes
PoC/PoE: Yes
IR Control: No
Downmix: No
Downscale: No
Over IP: Yes
HDBaseT: No
RS-232: Yes
AUDIO SUPPORT
HDMI™ Audio Formats: LPCM 2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-96/24, DTS-EX DSD, DTS High Res, DTS-HD Master, DTS:X
COMPLIANCES
HDMI™ Compliance HDMI™ 2.0b
HDCP Compliance HDCP 2.2
POWER
Power Consumption: Idle : 5.04W, Full load : 14.16W
Power Supply: Input: AC100 - 240V 50/60Hz
Output: DC 12V/2.5A (US/EU standards, CE/FCC/UL certified)
DIMENSIONS & WEIGHT
Transmitter: Length: 115.9mm / 4.56in
Width: 114.3mm / 4.5in
Height: 44.25mm / 1.74in
Weight: 350g / 12.34oz
PROPERTIES
Color: White panel + Black case
Housing: Aluminum panel + Iron case
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature: 20°C ~ 60°C / -4°F ~ 140°F
Operating Humidity: 20%~80% (relative humidity, non-condensing)
Storage Humidity: 10%~90% (relative humidity, non-condensing)
