In Stock: Usually Ships in 24 Hours

  • 2x2 Video wall controller
  • Multiple Display Modes: 2x2, 1x2, 2x1, 1x3, 3x1, 1x4, 4x1
  • Audio Formats: PCM 2.0



OREI UHD-202VW: 4K 2x2 Seamless Video Wall Controller

Seamless switching for distribution of any of the 4 input sources on any of the 4 output displays simultaneously, 4 Inputs & 4 Outputs. Perfect Professional Distribution Product, ideal for 4K Blu Ray Players, Game Consoles, Media Players, Satellite Receivers, Computers, Laptops, and Other Sources.

MULTIPLE SPLICING MODES: Multiple Display Modes - 2x2, 1x2, 2x1, 1x3, 3x1, 1x4, 4x1 and 1x4 Splitter Mode (Display the same source on all 4 TVs)


2x2 VIDEO WALL: This device easily lets you take one HDMI source (Blu Ray Player, Computer, Laptop, Media Player, Gaming Console) and divide on to 4 TV Display Screens simultaneously.

PLUG & PLAY - No extra software needed or Internet Required, Input with resolutions up to 4K/60Hz YUV 4:4:4,18GBPS, YUV 4:4:4, CEC, HDCP2.2.

Key Features:
  • Support one HDMI input resolution upto 4k@60Hz YUV 4:4:4
  • 4 HDMI output resolution fixed to 1080p@60Hz
  • Support HDMI 2.0 and HDCP 2.2
  • Supported Audio Formats - PCM 2.0
  • Support various display modes selectable via front button and remote control to combine up to 4 flat panel LCD TVs into one larger display
  • OSD - On screen display function
  • Power off memory function to keep the last setup status when power on

2x2 Video Wall Controller - UHD-202VW

  • Input Ports: 1 x HDMI Female
  • Output Ports: 4 x HDMI Female
  • HDMI 2.0
  • HDCP 2.2
  • Multiple Display Modes - 2x2, 1x2, 2x1, 1x3, 3x1, 1x4, 4x1 (1080i each Display) and 1x4 Splitter Mode (Display the same source on all 4 TVs @ 4K Each Display)
  • Interlaced upto 480i, 576i, 1080i
  • Progressive upto 480p, 576p, 720p, 1080p, 4K@24/25/30hz, 40K@50/60hz
  • Does Not Support HDR10, and Dolby Vision, Supported Audio Formats - PCM 2.0 (Does Not Support Dolby Digital and DTS
  • Supported Audio Formats - PCM 2.0
  • Vertical Freq uency Range: 50/60Hz
  • Video Amplifier Bandwidth: 6.0Gbps/600MHz per channel(l8Gbps all channels)
  • lnterlaced (50&60Hz): 480i.576i.l080i
  • Progressive(50&60Hz): 480p,576p,720p,l080p.4K@24/25/30Hz.4K@50/60Hz
  • Operating Temperature: 0°C ~ 70°C
  • Storage Temperature: 5% to 90% RH non -condensation
  • Splitter Unit Cert: FCC, CE, RoHS
  • Power Supply Cert: FCC, CE, RoHS
  • Dimensions (mm): 151(W) X 111(D) X 26.5(H)
  • Weight: 395g
  • Power Supply: 12V DC Power adapter
  • Power Consumption (Max): 12W
  • Material: Metal
  • Includes:
    • 1 x 2x2 seamless UHD Matrix
    • 1 x Matrix IR Remote
    • 1x User Manual
    • 1x Power Adapter 12V
  • Warranty:
    • 1 Year OREI Manufacturer's Warranty
