OREI 4K 4x1 KVM Switch with USB 3.0 and Multiview Functionality (UKM-401MV)

PRODUCT CODE:

OREI 4K 4x1 KVM Switch with USB 3.0 and Multiview Functionality (UKM-401MV)

~~$599.00~~ $299.00

In Stock: Usually Ships in 24 Hours

4 Inputs - 1 output HDMI Multiviewer switch
Video resolution up to 4K@60Hz, 2K@60Hz
KVM functionality

Quantity:

REQUEST A QUOTE

FREE SHIPPING WITHIN *USA ON ORDERS $50 & MORE

The UKM-401MV is a KVM Switch with 4 inputs, allowing you to access 4 computers using just one set of keyboard, mouse, and display. This device is HDMI 2.0b and HDCP 2.2 compliant, with a video bandwidth of 18Gbps and resolutions up to 4K@60Hz and 2K@60Hz. It also functions as a multi-viewer with 7 different display modes. Audio extraction is available through its optical and L/R ports. It features a built-in 3-port USB 3.1 Gen 1 hub for super-fast data transfer rates up to 5Gbps. Control the device via panel buttons, an IR remote, Keyboard and Mouse hotkeys, the OSD menu, or RS-232 commands. This device is compatible with both Windows and Mac, with no additional drivers needed for a simple plug-and-play setup. Its compact design makes it perfect for both commercial and personal uses.

Key Features:

HDMI 2.0b & HDCP 2.2 compliant
Video resolution up to 4K@60Hz and 2K@60Hz
18Gbps video bandwidth
Connect 4 computers and control them using a single set of Keyboard, mouse and display.
Built-in 3-port USB 3.1 Gen 1 hub with SuperSpeed 5Gbps data transfer rates, allowing you to share USB peripherals like printer, scanner, webcam, and hard disk between computers
Multiview functionality with 7 different modes
Easily switch between PCs using the keyboard/mouse hotkeys
Audio extraction through Optical and L/R outputs
Select which input the audio comes from and control the volume as well.
OSD navigation for advanced setting
EDID management
Control via front panel buttons, IR remote, keyboard/mouse hotkeys, OSD menu navigation, control software, RS-232 commands
Compatible with Windows and MacOS
No drivers required
Compact design for easy and flexible installation

Input: 4×HDMI Type A [19-pin female]
Output: 1×HDMI OUT Type A [19-pin female]
1 x L/R [Stereo, RCA]
1 x OPTICAL [S/PDIF]
Control Ports: 1 x RS-232 [3pin phoenix connector]
1 x IR Ext [3.5mm Stereo Mini-jack]
4 x USB 3.0 HOST [USB Type B]
2 x USB 2.0 DEVICE [USB Type A]
3 x USB 3.0 DEVICE [USB Type A]
Video Bandwidth: 18Gbps
Video Resolution: Up to 4K@60Hz and 2K@60Hz
Audio Formats:
HDMI: PCM 2.0/5.1/7.1, Dolby Digital/Plus/EX, DTS, DTS-96/24, DTS High Res, DSD
Analog audio [3.5mm L/R]: PCM 2.0
SPDIF (OPTICAL): Dolby Digital, DTS 5.1, PCM 2.0
Note: It does not support HBR audio.
Color Depth: 8/10/12 bit
Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
HDMI Compliance: HDMI 2.0b
HDCP Compliance: HDCP 2.2
Power Supply:
Input: AC 100 - 240V 50/60Hz
Output: DC 12V/2.5A
(US/EU standard, CE/FCC/UL certified)
Power Consumption (Max): 18.48W
RS-232 Command control via RS-232
Multiview Display all 4 sources in separate windows on the same display
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (Non-condensing)
ESD Protection: Human body model — ±8kV (Air-gap discharge) &±4kV (Contact discharge)
Length: 220mm / 8.66in
Width: 100mm / 3.93in
Height: 44mm / 1.73in
Weight: 443g / 15.62oz
Safety and Emission: CE | FCC | RoHS
1 × UKM-401MV 4x1 Multiviewer KVM Switch
1 × IR Remote
1 x 3pin-3.81mm Phoenix Connector (male)
1 x IR Receiver Cable (1.5 meters)
2 x Mounting Ears
4 x Machine Screw (KM3*4)
4 x USB Cable (USB 3.0 A to B, 1.8 meters)
1 x Power Adapter
User Manual
1 - Year Manufacturer's Warranty
